Schematic Diagram to Knowledge Graph & Agentic Verification
End-to-End Flow: 2D Engineering Schematics → Spatial Computer Vision & NMS → Topological Knowledge Graph → Model Context Protocol (MCP) Agent Swarm → Senior Reviewer Reflection & Automated Redline Scorecards.

1. From Static Diagrams to Living Knowledge Repositories

In technical industries, mission-critical engineering intent remains trapped in dense, multi-page 2D drawing sets—including Piping & Instrumentation Diagrams (P&IDs), Electrical Schematics, Single-Line Diagrams, and Process Flow Diagrams. Traditional engineering reviews require human subject-matter experts to manually cross-reference hundreds of sheets against engineering line lists, equipment indices, and regulatory standards.

We bridge this gap by transforming static CAD outputs and vectorized PDF drawings into connected, queryable Knowledge Graphs. Every line segment, instrument bubble, valve tag, inline component, and continuation boundary is extracted into an active entity layer, enabling instantaneous spatial, structural, and semantic reasoning.

This is proven in production: we have processed hundreds of P&IDs and their associated CAD drawings through these pipelines for engineering QA/QC.

Spatial Computer Vision & Continuation Logic

Our proprietary extraction engine applies targeted OCR combined with shape detection and Non-Maximum Suppression (NMS) to identify fine-grained schematic components with high coordinate accuracy:

  • Symbol & Instrument Bubble Classification: High-precision extraction of functional instrument tags (e.g., Pressure Transmitters, Flow Controllers, Level Alarms) and inline equipment.
  • Continuation Arrow Tracing: Automatically discovers off-sheet continuation arrows, matches bidirectional "To/From" labels across disparate drawing pages, and constructs unified topological process lines across entire plant sets.
  • Drawing Index & Title Block Surfacing: Extracts structural drawing numbers, revision flags, and project metadata with automated signature verification.

2. GraphRAG: Topological Grounding for Enterprise AI

Standard Vector RAG fails on technical diagrams because engineering questions demand topological path traversal (e.g., "What isolation valves exist between Pump P-101 and Vessel V-302 along line 4"-HC-1002?").

By storing schematic connectivity in Neo4j Property Graphs, we ground foundational multimodal models (such as Gemini on Vertex AI) directly in verified physical topology. The model can only report connections that exist in the graph: it traverses verified paths rather than guessing, enabling deep semantic interrogation of multi-discipline drawing packages.

3. Distributed Agent Swarms via Model Context Protocol (MCP)

We orchestrate audit and analysis tools using distributed FastMCP (Model Context Protocol) microservices. Rather than relying on monolithic prompts, specialized AI agents are invoked dynamically to perform dedicated tasks:

consistency_audit

Runs referential-integrity audits across the schematic, applies client-specific rules, and validates every finding through iterative self-review.

continuity_matching

Checks that specifications stay consistent wherever a line, tag or component is referenced across the pages of a large drawing set.

symbology_matching

Resolves generic and site-specific symbols against a data dictionary, adding each symbol's functional purpose and specification.

schematic_annotation

Marks every finding at the exact coordinates where it was observed on the original drawing, so engineers can verify it at a glance.

4. Two-Pass Senior Reviewer Reflection Architecture

Engineering safety demands zero-tolerance for AI hallucinations. Our architecture enforces a dual-stage execution model:

  1. Pass 1 (Draft Generation): The intake agent rapidly parses technical drawings utilizing multimodal context caching and extracts candidate findings against discipline rules.
  2. Pass 2 (Senior Reviewer Reflection): A secondary review agent rigorously audits every finding from Pass 1, verifying exact drawing coordinates, validating document citations, and eliminating false positives before scoring.

5. Safety Calculations & Automated Scorecard Generation

Our pipelines combine quantitative deterministic evaluation with qualitative LLM reasoning:

  • Pressure Safety Relief (PSV) Sizing Checks: Automatically compares design operating pressures against relief valve setpoints and discharge piping capacities.
  • Mechanical Line List Validation: Checks pipe specs, insulation ratings, design temperatures, and pressure classes across multi-sheet drawings.
  • Automated Deliverables: Generates structured multi-tab Excel Audit Scorecards alongside production-ready Annotated Redline PDFs complete with color-coded callouts.

6. Model Customization: Fine-Tuning for Your Drawing Conventions

Every firm draws its P&IDs a little differently. When prompting alone is not enough, we fine-tune models on your own validated examples so they learn your symbology, tagging rules and output formats:

  • Supervised Fine-Tuning (SFT): the model is trained on pairs of inputs and ideal outputs, such as a P&ID sheet with instructions alongside the validated instrument and equipment JSON an engineer signed off. It is the most direct way to teach your extraction conventions.
  • LoRA (Low-Rank Adaptation): instead of retraining every model weight, small adapter layers are trained and inserted into the model. This cuts GPU memory and training cost dramatically while keeping most of the benefit of full fine-tuning, and lets each client or drawing standard have its own lightweight adapter.

Multi-Channel Enterprise Intake

Workflows can be triggered seamlessly through multiple enterprise channels: direct SSE/REST API calls, Teams / Slack Bots, or Email (where engineers submit and communicate in lightweight, frictionless environments in batch or real-time).
